Handbook of Magnetic Measurements

Magnetism is a force of attraction or repulsion that acts at a distance. It is due to a magnetic field, which is caused by moving electrically charged particles. It is also inherent in magnetic objects such as a magnet. When performing a magnetic particle inspection, it is very important to be able to determine the direction and intensity of the magnetic field. As discussed previously, the direction of the magnetic field should be between 45 and 90 degrees to the longest dimension of the flaw for best detectability. The field intensity must be high enough to cause an indication to form, but not too high to cause nonrelevant indications to mask relevant indications. To cause an indication to form, the field strength in the object must produce a flux leakage field that is strong enough to hold the magnetic particles in place over a discontinuity. Flux measurement devices can provide important information about the field strength. A thorough overview of magnetic measurements, this handbook helps readers navigate the sometimes impenetrable terms of the field. It also assists them in the quest to design electromagnetic devices in a more effective way.
